Configuration manager

Configure before registering flags#

local window = Aroyn:CreateWindow({
    Parent = parent, Id = "preferences",
    Config = {Namespace = "my-game", AutoLoad = false, AutoSave = false},
})
local section = window:CreatePage({Name = "Settings", Icon = "settings"})
    :CreateSection({Title = "Preferences"})
local enabled = section:CreateToggle({Name = "Enabled", Flag = "enabled", Default = false})
section:CreateTextInput({Name = "Private value", Flag = "private", Sensitive = true})

local ok, info = window:SaveConfig("main")
if not ok then warn(info.Code, info.Message) end
window:LoadConfig("main") -- silent by default

Open full size ↗

Options#

ConfigureConfig can initialize an existing window before any Flag. The first registration otherwise creates the default manager. A second ConfigureConfig returns AlreadyConfigured. Invalid configuration options return InvalidOptions; invalid Config passed during CreateWindow/AttachWindow can assert.

Public methods#

Flags and exclusion#

Flag must be unique per Window, not per section: 1–64 ASCII letters/digits/underscore/hyphen, starting with a letter or digit. Name and construction order are not identifiers. Without a Flag, a value is not saved. RegisterConfig captures the default at registration.

Persist=false or Sensitive=true excludes that flag, including imported entries. JSON is plain text without encryption. No automatic token detection exists. Declare sensitive controls before loading; unknown valid flags are deferred until the library learns their type and exclusion policy.

Storage and schema#

File paths are relative to the executor workspace: AroynUILab/configs/<namespace>/<name>.json. Names and namespaces normalize to lowercase. Paths, extensions, periods, spaces and Windows device names are rejected. This format does not import old production Hub settings.

{
  "SchemaVersion": 1,
  "Namespace": "my-game",
  "Values": {
    "enabled": {"Type": "Toggle", "Value": true},
    "volume": {"Type": "Slider", "Value": 75},
    "mode": {"Type": "Dropdown", "Value": "Quiet"},
    "categories": {"Type": "Dropdown", "Multi": true, "Value": ["Pets"]},
    "note": {"Type": "Input", "Value": "Local note"},
    "shortcut": {"Type": "Keybind", "Value": {"Key": "H", "Mode": "Hold"}},
    "color": {"Type": "ColorPicker", "Value": {"R": 0.4, "G": 0.5, "B": 0.6}}
  }
}

Only SchemaVersion=1 is accepted. An empty single choice uses Value=false, a multi uses an empty array/table. Color channels are finite 0–1 numbers. Keybind stores the enum name or "None" and mode; it excludes active/pressed state.

Load and validation#

A missing, empty, corrupt, oversized (>256 KiB), wrong-namespace or unsupported-schema document returns an error without changing the UI. Up to 512 flags are supported. An invalid individual value is skipped with warnings; absent values retain current state. Save rejects invalid or oversized snapshots before writing.

Slider values clamp/quantize. Multi choices filter duplicates and removed options. A removed single choice falls back to an available construction default or nil. Invalid RGB, keys, modes, types and numbers are skipped. Text is limited to 16 KiB of UTF-8 bytes.

Valid unknown flags remain deferred for later registrations and round-trip through Save. A new Load replaces old deferred entries; Reset clears them. Load returns Applied, Deferred, Skipped and Warnings. Callbacks are silent unless InvokeCallbacks=true; activation is still suppressed. Changed controls receive at most one ordinary callback.

Filesystem capabilities#

FileSystem supplies plain synchronous functions, not methods requiring self. readfile(path) returns a string or throws; writefile(path, json), makefolder(path) and delfile(path) must throw on failure. Returning false from a custom writefile is not treated as an error. listfiles(directory) returns a table of path strings.

AutoSave and AutoLoad#

window:SetConfigAutoSave(true, "main", 0.75)
-- Only later changes schedule a write. Loading "other" does not
-- silently change the AutoSave destination.
local status = window:GetConfigStatus()
print(status.Mode, status.AutoSaveConfig)
if status.LastResult then print(status.LastResult.Code) end

AutoSave uses one debounce task per Window. Text edits and slider/color drags update pending state without writing every event. Manual Save, Load, Reset, disabling AutoSave and Destroy cancel the pending task. Destroy does not perform a hidden final flush. Check LastResult for automatic failures.

AutoLoad runs when the manager is created, before flags, and restores deferred values on registration. Check GetConfigStatus().LastResult immediately: ConfigureConfig returning Configured is not proof that the load succeeded. Explicit Load after constructing controls is easier to handle reliably.

Results and errors#

Operations normally return ok plus info containing Success, Code, Message and Mode. Success codes include Configured, Saved, Loaded, Listed, Deleted, Reset and AutoSaveChanged. A pre-manager invalid options result may not contain Mode.

A partial index error can include FileSaved=true or FileDeleted=true. Inspect the full result before retrying. Do not disguise an I/O error as a successful Session-mode operation.
